Compex WLE-1216V5-20 - Radio WiFi 5 GHz. 4x4 Mini PCIe Wave-2 AC1750
CMP-WLE-1216V5-20
Compex WLE1216V5-20
4x4 Wave-2 802.11ac/a/n Mini PCIe WiFi Module
- Full size form factor with 80+80MHz bandwidth support
- Qualcomm Atheros ‘Cascade’ QCA9984
- 5GHz max 20dBm output power (per chain)
- Heat sink allows free air operation
- IEEE 802.11ac compliant & backward compatible with 802.11a/n, up to 1733Mbps
- Multi-user MIMO (MU-MIMO) beamformer
- 4 spatial streams (4SS) at 80MHz
- 2 spatial streams (2SS) at 80+80MHz
- Mini PCI Express 2.0 interface
- Supports Spatial Multiplexing, Cyclic-Delay Diversity (CDD), Low-Density Parity Check (LDPC) Codes, Maximal Ratio Combining (MRC), Space Time Block Code (STBC)
- Supports Dynamic Frequency Selection (DFS)
- Designed for High Bandwidth Enterprise Wireless Access Points
| Producto | |
|---|---|
| Disponibilidad | Disponible |
| Súper Precio | Outlet |
| Marca | Compex |
| Tipo de Producto | Componente |
| Estándar WiFi | 802.11ac (WiFi5) |
| Wireless | |
|---|---|
| Frecuencia Wireless | 5 GHz. |
