Ubiquiti UniFi USW-16-POE - Switch Gigabit gestionable en Capa 2 de 16 puertos (8 puertos PoE 802.3af/at 42w) y 2 slots SFP, pantalla LCD
USW-16-POE
Gigabit PoE IEEE 802.3af / at PoE SFP Puertos para conectividad de fibra Gigabit Sin ventilador, refrigeración térmica silenciosa
Factor de forma compacto
Con solo 7.9 "de profundidad, el conmutador PoE UniFi está diseñado para instalación conveniente:
Montado en bastidor en un armario de bastidor SOHO
Montaje en escritorio
Conectividad de fibra Los puertos SFP permiten enlaces de red de hasta 1 Gbps.
Sin ventilador, enfriamiento silencioso
El conmutador PoE UniFi presenta refrigeración térmica silenciosa * sin ventilador, por lo que puede desplegarse en áreas donde el ruido del ventilador distraería. * Los interruptores sin ventilador no deben apilarse.
Rendimiento de conmutación
El conmutador PoE UniFi ofrece la capacidad de reenvío a procesa simultáneamente el tráfico en todos los puertos a velocidad de línea sin ningún paquete perdido.
802.3af / en PoE El soporte PoE simplifica su infraestructura de red y cableado.
PoE los puertos ofrecen 802.3af / at para alimentar sus dispositivos PoE, como AP UniFi y cámaras
- (8) puertos Gigabit RJ45 con 802.3af / at
- (8) puertos Gigabit RJ45
- (2) puertos 1G SFP
- Montaje en bastidor 1U (hardware incluido)
ESPECIFICACIONES
USW-16-PoE |
|
Dimensions |
442.4 x 200 x 43.7 mm (17.42 x 7.87 x 1.72") |
Weight |
2.80 kg (6.17 lb) |
With Brackets |
2.89 kg (6.37 lb) |
Interfaces |
|
Networking |
(16) 10/100/1000 RJ45 Ports (2) 1G SFP Ethernet Ports |
Management |
Ethernet In-Band |
Total Non-Blocking Throughput |
18 Gbps |
Switching Capacity |
36 Gbps |
Forwarding Rate |
26.78 Mpps |
Power Method |
100-240VAC, 50/60 Hz, Universal Input |
Voltage Range |
100 to 240VAC |
Max Power Consumption (Excluding PoE Output) |
18W |
LEDs System RJ45 Data Ports SFP Data Ports |
Status PoE, Speed/Link/Activity Link/Activity |
ESD/EMP Protection |
Air: ± 16 kV, Contact: ± 12 kV |
Shock and Vibration |
ETSI300-019-1.4 Standard |
Operating Temperature |
-5 to 40° C (23 to 104° F) |
Operating Humidity |
10 - 90% Noncondensing |
Certifications |
CE, FCC, IC |
PoE |
|
Total Available PoE |
42W |
PoE Interfaces |
|
Ports 1-8 |
POE+ IEEE 802.3af/at (pins 1, 2+; 3, 6-) |
Max. PoE Wattage per Port by PSE 802.3at |
32W |
Voltage Range |
|
802.3af Mode |
44-57V |
802.3at Mode |
50-57V |
Disponibilidad | No Disponible |
Marca | Ubiquiti |
Familia | Ubiquiti UniFi |
Tipo de Producto | Ethernet - Switch |
Tipo de Switch | Gigabit |
Puertos Switch | 18 |
Puertos PoE | 8 |
Puertos SFP | 2 |
Tipo PoE | 802.3at (PoE+) |
Tipo SFP | SFP 1G |
Potencia total PoE | 42 W |
